APTM50HM75STG

Part NumberAPTM50HM75STG

ManufacturerMicrosemi Corporation

DescriptionMOSFET 4N-CH 500V 46A SP4

DatasheetAPTM50HM75STG

Package / CaseSP4

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionMosfet Array 4 N-Channel (H-Bridge) 500V 46A 357W Chassis Mount SP4

To learn about the specification of APTM50HM75STG, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add APTM50HM75STG with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of APTM50HM75STG.
We are offering APTM50HM75STG for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

APTM50HM75STG - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays
Datasheet	APTM50HM75STG
Standard Package	1
Manufacturer	Microsemi Corporation
Series	-
Packaging	Bulk
Part Status	Active
FET Type	4 N-Channel (H-Bridge)
FET Feature	Standard
Drain to Source Voltage (Vdss)	500V
Current - Continuous Drain (Id) @ 25°C	46A
Rds On (Max) @ Id, Vgs	90mOhm @ 23A, 10V
Vgs(th) (Max) @ Id	5V @ 2.5mA
Gate Charge (Qg) (Max) @ Vgs	123nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds	5600pF @ 25V
Power - Max	357W
Operating Temperature	-40°C ~ 150°C (TJ)
Mounting Type	Chassis Mount
Package / Case	SP4
Supplier Device Package	SP4
