APTGLQ400A120T6G

Part NumberAPTGLQ400A120T6G

ManufacturerMicrosemi Corporation

DescriptionPWR MOD IGBT4 1200V 700A SP6

DatasheetAPTGLQ400A120T6G

Package / CaseSP6

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionIGBT Module Trench Field Stop Half Bridge 1200V 700A 1900W Through Hole SP6

To learn about the specification of APTGLQ400A120T6G, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add APTGLQ400A120T6G with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of APTGLQ400A120T6G.
We are offering APTGLQ400A120T6G for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

APTGLQ400A120T6G - Product Attributes

Categories

Discrete Semiconductor Products / Transistors - IGBTs - Modules

Datasheet

APTGLQ400A120T6G

Standard Package

Manufacturer

Microsemi Corporation

Series

Part Status

Active

IGBT Type

Trench Field Stop

Configuration

Half Bridge

Voltage - Collector Emitter Breakdown (Max)

1200V

Current - Collector (Ic) (Max)

700A

Power - Max

1900W

Vce(on) (Max) @ Vge, Ic

2.4V @ 15V, 400A

Current - Collector Cutoff (Max)

200µA

Input Capacitance (Cies) @ Vce

24.6nF @ 25V

Input

Standard

NTC Thermistor

Yes

Operating Temperature

-40°C ~ 175°C (TJ)

Mounting Type

Through Hole

Package / Case

SP6

Supplier Device Package

SP6
