Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet	ACGRAT101-HF~105-HF
Standard Package	1
Manufacturer	Comchip Technology
Series	Automotive, AEC-Q101
Packaging	Cut Tape (CT)
Part Status	Active
Diode Type	Standard
Voltage - DC Reverse (Vr) (Max)	600V
Current - Average Rectified (Io)	1A
Voltage - Forward (Vf) (Max) @ If	1V @ 1A
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr	5µA @ 600V
Capacitance @ Vr, F	8pF @ 4V, 1MHz
Mounting Type	Surface Mount
Package / Case	2010 (5025 Metric)
Supplier Device Package	2010
Operating Temperature - Junction	-65°C ~ 175°C
