Categories	Capacitors / Ceramic Capacitors
Datasheet	MLCC High-Q Caps Datasheet
Standard Package	2000
Manufacturer	Johanson Technology Inc.
Series	E
Packaging	Tape & Reel (TR)
Part Status	Active
Capacitance	10pF
Tolerance	±5%
Voltage - Rated	500V
Temperature Coefficient	C0G, NP0
Operating Temperature	-55°C ~ 125°C
Features	High Q, Low Loss, High Voltage
Ratings	-
Applications	RF, Microwave, High Frequency
Mounting Type	Surface Mount, MLCC
Package / Case	1111 (2828 Metric)
Size / Dimension	0.110" L x 0.110" W (2.79mm x 2.79mm)
Height - Seated (Max)	-
Thickness (Max)	0.102" (2.59mm)
Lead Spacing	-
Lead Style	-
