Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	PX Series
Standard Package	1
Manufacturer	Rubycon
Series	PX
Packaging	Cut Tape (CT)
Part Status	Active
Capacitance	22µF
Tolerance	±20%
Voltage - Rated	350V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	2000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	175mA @ 120Hz
Ripple Current @ High Frequency	262.5mA @ 10kHz
Lead Spacing	0.197" (5.00mm)
Size / Dimension	0.492" Dia (12.50mm)
Height - Seated (Max)	0.866" (22.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

25PX680MEFC10X12.5	Rubycon, 680µF 25V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, PX	View
16PX12000MEFC18X31.5	Rubycon, 12000µF 16V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, PX	View
63PX10MEFC5X11	Rubycon, 10µF 63V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, PX	View
35PX470MEFC10X12.5	Rubycon, 470µF 35V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, PX	View
25PX6800MEFC16X31.5	Rubycon, 6800µF 25V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, PX	View
100PX2R2MEFC5X11	Rubycon, 2.2µF 100V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, PX	View
50PX220MEFC10X12.5	Rubycon, 220µF 50V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, PX	View
10PX1000MEFC8X11.5	Rubycon, 1000µF 10V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, PX	View
16PX3300MEFCG412.5X20	Rubycon, 3300µF 16V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, PX	View
35PX330MEFC10X12.5	Rubycon, 330µF 35V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, PX	View
50PX330MEFC10X16	Rubycon, 330µF 50V Aluminum Electrolytic Capacitors Radial, Can 2000 Hrs @ 105°C, PX	View
35PX100MEFC6.3X11	Rubycon, 100µF 35V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C, PX	View

350PX22MEFCG412.5X20

Part Number350PX22MEFCG412.5X20
