2N3700UB

2N3700UB

Part Number2N3700UB

ManufacturerMicrosemi Corporation

DescriptionTRANS NPN 80V 1A UB

Datasheet2N3700UB

Package / Case3-SMD, No Lead

Unit PriceRequest a Quote

Lead TimeTo be Confirmed

Detailed DescriptionBipolar (BJT) Transistor NPN 80V 1A 500mW Surface Mount UB

To learn about the specification of 2N3700UB, please search the datasheet by clicking the link above. If you couldn't find the correct datasheet, please refer to the manufacturer's official datasheet.
To process your RFQ, please add 2N3700UB with quantity into BOM. Icapacitors.com does NOT require any registration to request a quote of 2N3700UB.
We are offering 2N3700UB for competitive price in the global market, please send us a quota request for pricing. Thank you!

Payment Methods
Delivery Services

2N3700UB - Product Attributes

Categories	Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Datasheet	2N3700UB
Standard Package	1
Manufacturer	Microsemi Corporation
Series	-
Packaging	Bulk
Part Status	Active
Transistor Type	NPN
Current - Collector (Ic) (Max)	1A
Voltage - Collector Emitter Breakdown (Max)	80V
Vce Saturation (Max) @ Ib, Ic	500mV @ 50mA, 500mA
Current - Collector Cutoff (Max)	10µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce	50 @ 500mA, 10V
Power - Max	500mW
Frequency - Transition	-
Operating Temperature	-65°C ~ 200°C (TJ)
Mounting Type	Surface Mount
Package / Case	3-SMD, No Lead
Supplier Device Package	UB
