Categories	Capacitors / Aluminum Electrolytic Capacitors
Datasheet	YXF Series
Standard Package	1000
Manufacturer	Rubycon
Series	YXF
Packaging	Bulk
Part Status	Active
Capacitance	1000µF
Tolerance	±20%
Voltage - Rated	25V
ESR (Equivalent Series Resistance)	-
Lifetime @ Temp.	10000 Hrs @ 105°C
Operating Temperature	-40°C ~ 105°C
Polarization	Polar
Ratings	-
Applications	General Purpose
Ripple Current @ Low Frequency	975mA @ 120Hz
Ripple Current @ High Frequency	1.3A @ 100kHz
Impedance	62 mOhms
Lead Spacing	0.197" (5.00mm)
Size / Dimension	0.492" Dia (12.50mm)
Height - Seated (Max)	0.866" (22.00mm)
Surface Mount Land Size	-
Mounting Type	Through Hole
Package / Case	Radial, Can

6.3YXF1000MEFC10X12.5	Rubycon, 1000µF 6.3V Aluminum Electrolytic Capacitors Radial, Can 6000 Hrs @ 105°C, YXF	View
10YXF1000MEFC10X16	Rubycon, 1000µF 10V Aluminum Electrolytic Capacitors Radial, Can 6000 Hrs @ 105°C, YXF	View
16YXF470MEFCT810X12.5	Rubycon, 470µF 16V Aluminum Electrolytic Capacitors Radial, Can 7000 Hrs @ 105°C, YXF	View
25YXF100MEFCTA6.3X11	Rubycon, 100µF 25V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, YXF	View
35YXF220MEFCT810X12.5	Rubycon, 220µF 35V Aluminum Electrolytic Capacitors Radial, Can 7000 Hrs @ 105°C, YXF	View
35YXF330MEFCT810X16	Rubycon, 330µF 35V Aluminum Electrolytic Capacitors Radial, Can 7000 Hrs @ 105°C, YXF	View
25YXF470MEFCT810X16	Rubycon, 470µF 25V Aluminum Electrolytic Capacitors Radial, Can 7000 Hrs @ 105°C, YXF	View
50YXF47MEFC6.3X11	Rubycon, 47µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, YXF	View
100YXF10MEFCT16.3X11	Rubycon, 10µF 100V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, YXF	View
16YXF1000MEFC10X20	Rubycon, 1000µF 16V Aluminum Electrolytic Capacitors Radial, Can 7000 Hrs @ 105°C, YXF	View
50YXF1MEFCT15X11	Rubycon, 1µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C, YXF	View
25YXF330MEFCT810X12.5	Rubycon, 330µF 25V Aluminum Electrolytic Capacitors Radial, Can 7000 Hrs @ 105°C, YXF	View

25YXF1000MEFC12.5X20

Part Number25YXF1000MEFC12.5X20
