Categories	Discrete Semiconductor Products / Diodes - Rectifiers - Single
Datasheet	1SS424
Standard Package	1
Manufacturer	Toshiba Semiconductor and Storage
Series	-
Packaging	Cut Tape (CT)
Part Status	Active
Diode Type	Schottky
Voltage - DC Reverse (Vr) (Max)	20V
Current - Average Rectified (Io)	200mA
Voltage - Forward (Vf) (Max) @ If	500mV @ 200mA
Speed	Small Signal =< 200mA (Io), Any Speed
Current - Reverse Leakage @ Vr	50µA @ 20V
Capacitance @ Vr, F	20pF @ 0V, 1MHz
Mounting Type	Surface Mount
Package / Case	SC-75, SOT-416
Supplier Device Package	SSM
Operating Temperature - Junction	125°C (Max)
